EIFS-External-Insulation-Finish -System (Stucco) The diagram on the right describes how the system is installed. Poor flashing
around the windows and other openings allows water to enter behind the foam board and can't dry out. This promotes rot and other
things to grow (mold) and /or fall apart.
Infrared can help find the places to start looking.
704-200-6367
Charlotte's only HVAC & Building commissioning experienced thermographer.
Temperatures are important but with thermal images you get the whole picture.
I can find your energy loss fast.
704-200-6367
Danny Lipford and I
Charlotte,NC
  • Do you have energy loss?
  • Did the insulation contractor
    complete the job?
  • Does your AC/Heat run all
    day?
  • Do you have a water leak?
  • Does your horse ache?
  • Have an Infrared Survey .
Thermal Imaging has been around for decades mostly in the military. With todays rapid technology it is now
affordable . Thermal imagers see only heat or the lack of heat,many materials conduct heat at different rates. Call for
estimate we offer a  Multi house discount. Many times there are more than 1 home in a neighborhood with the same
problem.
I have been in the HVAC and thermography trade  since
1989

Certified  Level II Vibration &, Thermographer and
Mechanical Journeyman ,ASNT Level II Machine Analyst
  • TOP 5 HOME ENERGY LOSS AREAS
  • 1 ATTIC DOOR
  • 2-NON-PROGRAMMABLE THERMOSTATS
  • 3-DUCT WORK LEAKS
  • 4-LACK OF OUTLET GASKETS
  • 5-WINDOWS&DOOR SEALS
  • TOP BUILDING ENERGY LOSS ISSUES
  • 1-The HVAC and controls.Just a minor adjustment to the
    controls can save 20%
  • 2-Lighting and lighting controls
  • INFRARED THERMAL IMAGING HAS MANY
    APPLICATIONS
  • Energy Loss
  • HVAC issues
  • Plumbing leaks
  • Roof leaks
  • Electrical
  • Marine
  • Equine
Recommended and
Approved by the dept of
energy-- click to read
about infrared
Presented  papers for-- click
July 07 issue- Uptime mag

& SNELL Thermal Solutions 08 in FL
Media resume
Hot breaker in your house can
be a fire hazard
White lines are under floor hot water
heating pipe -Gray pallet (under 6
inches of concrete)
HEAT LOSS AROUND
OUTLETS AND WINDOW
FRAME WORK
Typical attic door loosing lots
of energy try the
The attic tent
Roof top AC unit with blocked
condenser and cold air leaks
This boiler has a cracked refractory seen
without tearing down boiler on a routine
survey
-The Platinum energy Group
Leaking Steam Traps cost thousands of
lost dollars. IR Combined with
Ultrasound is most beneficial.
Enercheksystems
Building with heat loss which is heat gain in the summer. The heat gain in the summer can
cause condensation which could grow mold
HEAT LOSS ABOVE
WINDOW-MISSING
INSULATION
I can image many items including livestock and marine
Horses can be imaged as well to help the Vet diagnose issues. IR is non-contact
and non-invasive. Infrared is another set of eyes .The vet needs all they can get...
Ever buy a boat to find out later it leaks or was
hit-.IR can see what is under the fiberglass
Data floors need to air tight
to exterior so the computer
equipment can have
maximum HVAC efficiency
Danny uses us for
his shows
Contact Us
President-John Cannamela
Level II Certified 050916-6
HVAC- journeyman card
Universal CFC
Serving but not limited the Charlotte ,NC
area
704-200-6367
